Getting Started with the Philips Hue REST API

Austen·

The Philips Hue smart lighting ecosystem is robust, flexible, and offers a number of out-of-the-box features that go a long way to delivering a powerful smart home experience.

However, the primary methods for interacting with the system has some limitations that hinder the quest to achieve our true Smart House (1999) vision.

Trust me — it’s not as hard to use as it sounds.

Enter the Hue REST API – a powerful set of tools for developers to expand the functionality of their Hue systems.

An application programming interface, or API, is an interface that defines interactions between different software services. In this case, we want to use the API to bypass the Hue app and directly interact with the Hue Hub to control our lights and sensors.

Philips has opted to use a REpresentational State Transfer, or “REST” API to enable developer interactions. REST APIs use HTTP requests (GET, PUT, POST, and DELETE) to tell the end software what to do.

Trust me — it’s not as hard as to use as it probably sounds. Gaining access to the Philips Hue REST API is the first step to enable you to expand and automate the functions of your smart lights and sensors.

How to Access the Philips Hue REST API

You have a few options for interacting with the Hue API.

  • Your Browser: Since we are just using HTTP, you can run all of these commands via the address bar in your browser
  • Hue Clip API Debugger: You can interact with an interface provided by your Hue Hub at https://<hub IP address>/debug/clip.html
  • A REST API Client: There are many options available, but I recommend the Advanced REST Client Chrome extension

In this guide, I’ll be using the CLIP API Debugger (after step 1)

1. Find the IP address of your Hue Hub

To get started, you need to know the IP address of your hub. The easiest way to get this is via discovery.meethue.com

Go to this link while connected to the same network as your hub, and you’ll get something like this:

[{"id":"001788fffeffe7b7","internalipaddress":"10.0.0.192"}]

Document this IP address somewhere safe. You’re going to use it a lot.

a screenshot of the Hue Hub CLIP API Debugger

2. Create an Authorized User

In order to interact with the API, you need to create an Authorized User.

Navigate to your hub’s CLIP API Debugger by typing the following in your browser:

http://<YOUR HUB IP>/debug/clip.html

In my case, that’s:

http://10.0.0.192/debug/clip.html

You should see a window like the one on the right.

Here, you need to issue a command to create a new authorized user. To do this, fill out the following fields:

        URL: /api
Message Body: {"devicetype":"my_hue_app#iphone austen"}

This command is telling the hub to create a new user in the location /api, where users are stored.

Note that all message content is in JSON (JavaScript Object Notation) format.

Go ahead and click POST. You should get an error that says the Hub Button was not pressed.

Go push it, come back, and click POST again. You’ll get output like the following:

[
    {
        "success": {
            "username": "GI55xM2PlF9LwRtJHN2t0cgh9hQvve5AyN1788KB"
        }
    }
]

Document this username somewhere safe. Like the hub IP address, you’re going to use this a lot.

Important!

This username grants full access to your Hue lighting system. While it is only useful by people who are on your network, I recommend keeping it somewhere safe and secret to keep your smart home secure.

3. Start using the REST API

You now have all of the tools you need to start using the REST API! There are a few things you should know.

To continue using the CLIP interface, replace the URL field with /api/<YOUR USER>/

Generally, querying the system for device and rule lists or current device states is done using GET commands. For example, if you want to get a list of the Sensors in your system, you would put the following into the URL field:

/api/GI55xM2PlF9LwRtJHN2t0cgh9hQvve5AyN1788KB/sensors

Click GET. Your output will look something like this:

{
	"1": {
		"state": {
			"daylight": false,
			"lastupdated": "2020-09-08T01:20:00"
		},
		"config": {
			"on": true,
			"configured": true,
			"sunriseoffset": 30,
			"sunsetoffset": -30
		},
		"name": "Daylight",
		"type": "Daylight",
		"modelid": "PHDL00",
		"manufacturername": "Signify Netherlands B.V.",
		"swversion": "1.0"
	},
	"2": {
		"state": {
			"buttonevent": 3003,
			"lastupdated": "2020-09-08T01:46:40"
		},
		"swupdate": {
			"state": "batterylow",
			"lastinstall": null
		},
		"config": {
			"on": true,
			"battery": 38,
			"reachable": true,
			"pending": []
		},
		"name": "Hue dimmer switch 1",
		"type": "ZLLSwitch",
		"modelid": "RWL020",
		"manufacturername": "Signify Netherlands B.V.",
		"productname": "Hue dimmer switch",
		"diversityid": "73bbabea-3420-499a-9856-46bf437e119b",
		"swversion": "5.45.1.16265",
		"uniqueid": "00:17:88:01:10:33:6a:5c-02-fc00",
		"capabilities": {
			"certified": true,
			"primary": true,
			"inputs": [
				{
					"repeatintervals": [
						800
					],
					"events": [
						{
							"buttonevent": 1000,
							"eventtype": "initial_press"
						},
						{
							"buttonevent": 1001,
							"eventtype": "repeat"
						},
						{
							"buttonevent": 1002,
							"eventtype": "short_release"
						},
						{
							"buttonevent": 1003,
							"eventtype": "long_release"
						}
					]
				},
				{
					"repeatintervals": [
						800
					],
					"events": [
						{
							"buttonevent": 2000,
							"eventtype": "initial_press"
						},
						{
							"buttonevent": 2001,
							"eventtype": "repeat"
						},
						{
							"buttonevent": 2002,
							"eventtype": "short_release"
						},
						{
							"buttonevent": 2003,
							"eventtype": "long_release"
						}
					]
				},
				{
					"repeatintervals": [
						800
					],
					"events": [
						{
							"buttonevent": 3000,
							"eventtype": "initial_press"
						},
						{
							"buttonevent": 3001,
							"eventtype": "repeat"
						},
						{
							"buttonevent": 3002,
							"eventtype": "short_release"
						},
						{
							"buttonevent": 3003,
							"eventtype": "long_release"
						}
					]
				},
				{
					"repeatintervals": [
						800
					],
					"events": [
						{
							"buttonevent": 4000,
							"eventtype": "initial_press"
						},
						{
							"buttonevent": 4001,
							"eventtype": "repeat"
						},
						{
							"buttonevent": 4002,
							"eventtype": "short_release"
						},
						{
							"buttonevent": 4003,
							"eventtype": "long_release"
						}
					]
				}
			]
		}
	},

As you can see, I have a number of Hue Switches and other sensors in my environment.

This section shows me that my Switch, “Hue dimmer switch 1”, is low on battery:

	"2": {
		"state": {
			"buttonevent": 3003,
			"lastupdated": "2020-09-08T01:46:40"
		},
		"swupdate": {
			"state": "batterylow",
			"lastinstall": null
		},
		"config": {
			"on": true,
			"battery": 38,
			"reachable": true,
			"pending": []
		},
		"name": "Hue dimmer switch 1",
		"type": "ZLLSwitch",
		"modelid": "RWL020",
		"manufacturername": "Signify Netherlands B.V.",
		"productname": "Hue dimmer switch",
		"diversityid": "73bbabea-3420-499a-9856-46bf437e119b",
		"swversion": "5.45.1.16265",
		"uniqueid": "00:17:88:01:10:33:6a:5c-02-fc00",
		"capabilities": {
			"certified": true,
			"primary": true,
			"inputs": [
                               ...

I should probably take care of that.

On the flip side, the PUT command will be used to tell your system to do something, like turning on a light.

The full list of available commands and interactions is available on the Philips Hue Developer website. A free login is required – I highly recommend creating one.

Play around with your Hue API and see the possibilities! What do you plan on automating in your environment?
